| Construction: |
|
|
| |
|
|
| Hull and Superstructure are of Steel |
|
|
|
| LOA: |
70.0 |
meters |
| Beam: |
13.0 |
meters |
| Draught: |
5.0 |
meters |
| Gross Ton: |
1.658 |
|
| Net Ton: |
497 |
|
|
|
|
| Class: |
|
|
| |
|
|
| Det Norske Veritas 1A1, cargo ship, ICE.1CMV, E0 (unmanned engine room) |
|
|
| |
|
|
| Accommodation |
|
|
| |
|
|
| For 40 people (crew, scientists and / or passengers) in single cabins. |
| Mess room, salon and library / conference room new 1992-93. Sauna. |
| 4 offices, 6 laboratories, 4 workshops and 1 hospital with 4 beds. |
| Full Air condition. |
|
|
|
|
|
| Engines & Auxiliaries: |
|
| Engine room was totally rebuilt 1986 with all asbestos taken out. |
|
|
|
| Main Engines: |
Bergen Diesel KRMB-9 2.250 Hp, new 1986 |
| Auxiliary generators: |
2 X Cummins 250 KW and shaft generator 800 KW |
| Propulsion system: |
Variable pitch propeller |
| Speed: |
Top speed 14 knots service speed 12 Knots |
| Range: |
7.000 nm / 30 days |
| Separators: |
1 x for oily water |
|
1 for diesel oil Alfa Laval, |
|
1 for engine oil Alfa Laval |
| Water Maker. |
5 ton / day |
|
|
|
| Deck equipment |
|
|
| |
|
|
| Cranes |
Bow |
Tico Marine 100 1.1 ton / 8.3 meter |
|
STB side |
Custom marine crane 1.5 ton / 8 meter |
|
Port side |
Karmöy Marine 5 ton / 9 meter |
|
Aft |
Tico Marine 130 1.5 ton / 8.3 meter |
|
|
|
| Winches |
2 x 4000 m Trawl |
|
1 x Mocness |
|
1 x Hydrographic |
|
1 x CTD |
|
|
1 x Cable winch for trawling |
|
|
|
| Tank Capacity |
|
|
| |
|
|
| Fuel: |
359 m3 |
|
| Fresh water: |
97 m3 |
|
| Ballast: |
90 m3 |
|
|
|
|
| Safety |
|
|
| |
2 x Lifeboats, 64 person |
|
5 x Liferafts |
|
50 Life west’s |
|
40 Survival suites |
|
|
|
| Communication |
|
|
| |
|
|
| Sat com |
NERA Saturn B Thrane & Thrane Inmarsat C |
|
|
|
| Radio |
|
|
| |
|
|
| GMDSS Area 3 |
1 x Skanti TRP 5001 |
|
1 x Skanti Watch WR 6020/2182 KHz |
|
2 x Skanti GMDSS Emergency VHF Transceiver |
|
1 x SP Radio RE 2100 Sailor Compact 600 W MF / HF |
|
1 x SP Radio R 2120 HF SSB Duplex Receiver |
|
2 x SP Radio Sailor HF SSB 600 W PEP |
|
2 x SP Radio RT 146 VHF Transceiver |
|
1 x SP Radio RT 2047 Compact VHF |
|
1 x SP Radio Telex H 2098 |
|
1 x SP Radio Watch RM 2042 / VHF / DSC |
|
1 x SP Radio HF SSB N 2165 |
|
2 x SP Radio Receiver Protection Unit 1223 |
|
2 x Radio GMDSS Emergency VHF Transceiver Sailor SP 3110 VHF |
|
2 x SP Radio Sailor Compact Control Unit C 2140 |
|
1 x SP Radio Sailor Compact VHF RT 2048 |
|
1 x Dancall TR 1101 |
|
2 x Tron Sart 9 GHz Radar Transponder |
|
1 x Tron 30 S MK 11 Cospas / Sarsal EPIRB |
|
2 x TRP 1 Radio Life boat |
|
3 x VHF Emergency Beacom CS 1 N |
|
|
|
| Network |
|
|
| |
|
|
| |
LAN (local area network) |
|
|
|
| Navigation |
|
|
| |
|
|
| Radar |
Furuno FR 2110 |
|
Krupp Atlas 7600 AC / TMX |
|
Raytheon RM 12670 / SS |
|
|
|
| GPS |
Trimble NT 200 D |
|
Leica AP MK 12 DGPS |
